Sab nraum zoov 10x60W LED Tsiv Lub Taub Hau Beam Teeb

Guangdong Tshiab Pib Teeb pom kev zoo Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm 10x60w coj txav taub hau teeb lub teeb nyob hauv Suav teb. Nrog kev paub ntau, peb sov siab txais tos koj rau cov lag luam wholesale customized teeb pom kev zoo ntawm tus nqi sib tw los ntawm peb lub hoobkas. Tiv tauj peb rau pricelist.

1. Core configuration

• Lub teeb qhov chaw: 10 60W RGBW plaub- xim lub teeb tseem ceeb hlaws (ib zaug - taw tes tswj kev ywj pheej) + 140-288 0.3W / 3W auxiliary lub teeb hlaws (xws li RGB, txias, sov thiab dawb), tag nrho lub zog kwv yees li 800W, txaus ci.
• Kev tiv thaiv: Kev ntsuas dej tsis zoo txog IP65 / IP66 / IP67 (txhawb los nag thiab dej wading), nrog cam khwb cia txhuas vaj tse + kaw tsim, tsim rau sab nraum zoov suab paj nruag festivals, kab lis kev cai thiab tourism kev ua yeeb yam thiab lwm yam scenarios.

2 Core nta

Kev sib xyaw ua ke:

• Beam: 2.8℃-31℃tsom rau kev ua kom ntse, dav kab;
• Dyeing: RGBW tag nrho xim sib xyaw + 32-ntsis linear dimming kom zoo thiab txawm xim;
• Dynamic teebmeem: Y-axis 202℃-270℃co, 1-30Hz stroboscopic, khiav nees, dej ntws, particle teebmeem (lub teeb tseem ceeb + lub teeb lub teeb tuaj yeem ua haujlwm ntawm nws tus kheej hauv sync).
• Tswj hom: Txhawb DMX512, pib-tsav, tswv- qhev, lub suab- tswj nrog RDM muaj nuj nqi, mus txog 186 raws kom tau raws li cov kev cai ntawm kev tshaj lij.

• Khoom npe: Sab nraum zoov 10x60W LED Tsiv Lub Taub Hau Beam Teeb
• Qauv Zauv: NST-1060

• Lub teeb ci tseem ceeb: Osram RGBW 10 60W hlaws
• Stroboscopic auxiliary lub teeb:
• 96 2W CW LED
• 96 2W WW LED
• 96 1W RGB LED

• Lub kaum sab xis: Beam Angle: 2.8℃-31℃(beam kawg)
• Spot Angle: 5℃-46℃(dye kawg)
• Xim kub: 2800K-8500K
• Tag nrho cov teeb tso zis illuminance: 21460Lux @ 5 m
• Lub teeb hlaws lub neej: 80,000 teev

• Mixing systems: Uniform RGBW sib xyaw tshuab thiab cov teebmeem zaj sawv
• Zoom system: Linear fais zoom
• Ib qho - taw tes tswj: Lub teeb qhov chaw txhawb kev tswj hwm ywj pheej rau ib leeg, nrog rau kev hloov pauv zoo heev
• Cov nyhuv macro: Cov nyhuv zoo li qub macro thiab cov nyhuv dynamic macro zog
• Dimming: 0-100% 16-ntsis zoo dimming nrog plaub dimming nkhaus
• Stroboscopic: 1-30Hz hluav taws xob stroboscopic thiab random stroboscopic

• LCD zaub ua lus Suav thiab lus Askiv, nrog cov ntawv sau tau thim rov qab.
• Y-axis scan lub kaum sab xis: 202℃-270 degree
• Kev tiv thaiv ntsuas: IP65+ rau kev siv sab nraum zoov
• Dot matrix effect: Cov pab pawg sab laug thiab sab xis tuaj yeem tswj tau nyias, txhua LED tuaj yeem tswj tau ntawm nws tus kheej, muaj yeeb yuj thiab dazzling chase nyhuv
• tswj hom: pib- tsav hom, tswv- qhev hom thiab DMX512 tswj hom
• Tswj raws tu qauv: Standard DMX512, RDM raws tu qauv
• Kev txhawb nqa kev ua haujlwm hauv network: Artnet, Klingnet, SACN network raws tu qauv
• Cov ntaub ntawv kev sib txuas: RJ45 network chaw nres nkoj nkag / tawm, peb -core lossis tsib-core teeb liab tawm tswv yim / tawm

• Tag nrho lub zog: 800W
• Lub hwj chim: 100V-240V 50-60Hz
• Ua haujlwm ib puag ncig: Txhua qhov chaw ua haujlwm nyab xeeb iav tsom iav
• Ua haujlwm kub: -20 ℃ to 40 ℃

• Siab - lub cev muaj zog lub suab nrov kom pom tseeb, tsis muaj qhov tsis txaus ntseeg
• Hwj chim ceev ceev stroboscopic nyhuv, siab -cov duab txhais tsis flicker
• Kev ua kom muaj cua sov ua kom zoo, kev saib xyuas qhov kub thiab txias, siab - kub tsis siv neeg hloov kev tiv thaiv, tsis muaj kev pheej hmoo ntawm teeb puas
• Intelligent ceev- tswj kiv cua, tiag- lub sijhawm ntsuas kub
• Chassis qauv: High-kub resistant engineering yas puab pwm, siab-hardness hlau, ntau lub teeb lub cev xim xws li dub, dawb, grey, thiab lwm yam. Koj tuaj yeem xaiv dawb raws li koj xav tau

• Ntev: 1010mm (39.76 ")
• Dav: 151mm (5.94 ")
• Qhov siab: 332mm (13.07 ")
• Net nyhav: 26kg (57.2bs)

• Ntev: 1070mm (42.12 ")
• Dav: 570mm (22.44 ")
• Qhov siab: 570mm (22.44 ")
• Net nyhav: 106 kg (233.2lbs) (nrog rau tus qauv 1 hauv 3 airbags)

• Kev tiv thaiv chav kawm: IP20
• Kev khiav hauj lwm ib puag ncig: -20 ℃ to 45 ℃
• Qhov kub siab tshaj plaws ntawm lub teeb lub cev: 65 ° C
• Qhov siab tshaj plaws tam sim no ntawm lub teeb: 1.9A / 220V; 4.3 A / 110 v

• ISO9001 Kev Tswj Xyuas Kev Tswj Xyuas Zoo tau ntawv pov thawj
• Daim ntawv pov thawj CE

• Nws tuaj yeem ntsia tau horizontally lossis vertically
• Universal txoj haujlwm ua haujlwm
• 2 tsau lub teeb hooks rau 50mm lub teeb sawv
• Kev ruaj ntseg hlua txuas qhov

• Electronic Instruction Manual
• Fais fab qaum, teeb liab qaum, hangers 1 set
• Ob lub teeb hooks haum rau 50mm lub teeb sawv
